 4×4 Winchline:

Stealth Fibre:

4×4 Winchline: Stealth Fibre is designed for high load applications where exceptionally low weight is required-making for an excellent wire rope replacement. The heat treatment and polyurethane coating applied increases the rope’s abrasion resistance, prolonging its life. We custom make to order, 100% New Zealand spliced by internationally certified splicers.

This rope is designed for high load applications where exceptionally low weight is required—making for an excellent wire-replacement rope. The heat treatment and polyurethane coating applied increases the rope’s abrasion resistance, prolonging its life.

4×4 Winchline: Diameters & Break loads:

4mm=(MBL 2,100kgs), 5mm=(MBL 3,000kgs),

6mm=(MBL 4,300kgs), 7mm=(MBL 5,200kgs),

8mm=(MBL 6,500kgs), 10mm=(MBL 9,700kgs),

12mm=(MBL 15,300kgs), 14mm=(MBL 17,900kgs)

& 16mm=(MBL 21,100kgs)

4×4 Winchline:

Splicing:    If you require your 4×4 winchline spliced there is an extra charge. Remember to point this out when ordering your winchline, also if you want a soft eye splice or thimble eye splice because there is a difference in price.

All our splicing is done inhouse by Total Rope Worx NZ Ltd, all our splicers are internationally certified.

100 % New Zealand designed & spliced

FEATURES

• Extreme strength-to-weight ratio
• 15 x stronger than steel wire rope
• Safer than wire rope(low recoil)
• Hydrophobic fibre (no water absorption)
• Floats
• Low creep
• Easy to splice
• Resistant to kinking
• Maintains high strength around tight-radius bends
• Exceptional UV and chemical resistance
• Abrasion-resistant coating reduces likelihood of snagging and provides superior winch drum grip

APPLICATIONS

• Wire rope replacement
• Winchlines
• Winchline Extensions
• Soft Shackles
• Towing
• Lifting
• Strops

TECHNICAL

Material: Stealth Fibre
Construction: 12-Strand Single Braid
Treatment: Heat-set with polyurethane coating

STANDARD RANGE

Diameters: 1 – 105 mm (larger diameters available on request)
Reel Length: 200 m
Colour: Silver-grey

OPTIONS

• Available in 2 constructions:
  • Single strand (1 – 9 mm)
  • Double strand (10 – 60 mm)
• Custom colours (silver-grey standard)
• Larger diameters
• Spliced soft eyes
• Spliced thimbles eyes

Give us a call if you need anymore info about our 4×4 Winchlines.
